Adding/Configuring an IBM TSM Server within the Data Collector Policy Version 10.0.01

Add IBM TSM servers/instances by clicking Add, or by importing using a .CSV file. The IBM TSM Instances table is populated using this method. Servers added to this table are also displayed under Host Management and Host Group Administration. The IBM TSM Instances table only displays available Instances that are not assigned to other policies within the domain.

Note: Data Collector policies can be in place for multiple instances but an instance cannot be assigned multiple policies within the same domain. If you try add an instance that is already assigned to another Data Collector policy, you will be prompted to remove it from its current policy and reassign it.

1. Click Add on the IBM Tivoli Storage Manager Data Collector Policy screen. The Add IBM Tivoli Storage Manager Instance screen displays.

Field	Description
Instance Name	The name assigned to the IBM TSM instance. This is a separate instance of the server software running on a IBM TSM server. A single IBM TSM server can run multiple IBM TSM instances. An instance is defined by instance name, host name, and port number.
Host Name	The name of the IBM TSM server. This is the host running the IBM TSM server software. This system will be known by its host name. If you do not know the Host Name, you can enter the IP Address in this field.
Host IP Address	The IP address of the host running the IBM TSM server software. By default it is set to 127.0.0.1. You can revise it as required and this field is not mandatory.
Host Port	Port number used by dsmadmc to communicate with the IBM TSM Instance. Each instance will have its own specific port. By default it is set to 1500. You can revise it, but the field is required.
User ID	IBM TSM user ID with query and select privileges.
Password	Password associated with the IBM TSM administrator account credentials.
